Card Connector, Connector, Mini PCI Express Socket

119A-70A00-R02

Name: 119A-70A00-R02
SKU: 119A-70A00-R02
Availability: BackOrder

Availability:

Available on Backorder: Manufacturer lead time 10-12 weeks

Mini PCI Express Socket, H=7.0mm, GF

$1.232 USD

Available on Backorder: Manufacturer lead time 10-12 weeks

Packing: Reel
MPQ: 450
MOQ: 450

ATTEND’s Mini PCIe card connectors can support Storage SSD and WiFi, Bluetooth, global navigation satellite systems, near field communication. PCI-SIG standard compliant.
● 0.8mm pitch and a 52-pin configuration with varying heights.
● Latches are available for selected heights.

ELECTRICAL

Current Rating	0.5A per pin
Voltage Rating	50V AC
Contact Resistance	30mΩ
Insulation Resistance	500MΩ
Dielectric Withstanding Voltage	250VAC

MECHANICAL

Durability	50Cycle
Insertion Force	50gf per pin min
Extraction Force	180gf per pin min.

ENVIRONMENTAL

Operating temperature range	-40℃~+90℃
Storage temperature range	-40℃~+90℃

SOLDER ABILITY

Recommended IR Reflow (Wave Soldering) Temperature	260℃

SKU: 119A-70A00-R02 Categories: Card Connector, Connector, Mini PCI Express Socket

Country Of Origin	CN

Brand

Attend
