119A-92A00-R02

$1.372 USD

Mini PCI Express Socket, H=9.2mm, GF

Available on Backorder: Manufacturer lead time 10-12 weeks


For More than 5000 pcs, You can contact us and request for price
SKU: 119A-92A00-R02 Categories: , ,

Description

Packing: Reel
MPQ: 300
MOQ: 300

ATTEND’s Mini PCIe card connectors can support Storage SSD and WiFi, Bluetooth, global navigation satellite systems, near field communication. PCI-SIG standard compliant.
● 0.8mm pitch and a 52-pin configuration with varying heights.
● Latches are available for selected heights.

MATERIAL

Plastic Body LCP, Color Black
Contact Phosphor Bronze Alloy (C5191R-H) Contacts Rating
Contacts Rating Contact Area: Gold Plated
Solder Area Tin
Hold Down Brass (C2680R-H)
Hold Down Plating Tin

ELECTRICAL

Current Rating 0.5A Max. /1pin
Voltage Rating 50V AC
Contact Resistance 30mΩ Max.
Insulation Resistance 500MΩ Min.

MECHANICAL

Contact Normal Force 50gf per pin Min.
Durability 100 mating and unmating cycles

ENVIRONMENTAL

Operating temperature range -40℃~+90℃
Storage temperature range -40℃~+90℃
Solder Ability 260±5℃

Additional information

Country Of Origin

CN

Brand

Attend
