Mini-XL

Mini-XL

Product Description

  • ITT XLB male and female PCB flange mount receptacles are plastic
  • Low cost alternative to our metal XLM-CPB Connectors
Category: Tags: ,
ITT Cannon

Description

Feature:

  • 40% smaller than standard XLR
  • Rugged design to withstand extreme field use
  • Ideal for high density applications
  • Quick disconnect latch lock

Mechanical

APPLICATION / MARKET: Aerospace, Defense, Industrial, Transportation
SHAPE: Circular
SHELL STYLE: Cable connecting plug, flange and front mount receptacle
DURABILITY: 500 Mating Cycles
POWER & SIGNAL IN SAME LAYOUT: No
CONTACT STYLE / TERMINATION: Solder

Material

SHELL: Copper
SHELL PLATING: Nickel
INSULATOR: PPS (polyphenylene sulfide)
CONTACT: Copper
CONTACT PLATING: Gold

Electrical

OPERATING VOLTAGE: 125 VAC
CURRENT RATING: 3A
NUMBER OF SIGNAL CONTACTS (MIN/MAX): 3-6
GAUGE WIRE SIZE: 24 AWG

Environmental

SEALING: Not Available
OPERATING TEMPERATURE: -35°C to +85°C,
