SD-M8A-06P-FF-SH7B50-XXAH

  • Number of contacts: 6
  • Coding: A-coded
  • Rated current: 1.5A
  • Rated voltage: 30V AC,30V DC
  • IP Rating: IP67
  • Operating temperature: -25~80°C

Description

Specification

Convention
Standard M8 IEC   61076-2-104
Number of contacts 6
Coding A – coded
Connector Style 180°Female
Termination Solder
Operating temperature -25 °C … +80   °C
IP Rating IP67
Mechanical operation >100
Torque 0.3 Nm … 0.4   Nm
Installation type Front mounting M8   x 1.0
Electrical properties
Rated current (40oC) 1.5A
Rated voltage 30V AC,30V DC
650V
Contact resistance <10mΩ
Insulation resistance ≥100MΩ
Degree of pollution 3
Overvoltage category II
Material
Flammability rating according to UL 94 V0
Contact material CuZn
Contact surface material Au
Contact material PA
Sealing material NBR
Cable gauge
Conductor   cross section 0.14mm²
AWG   signal line 26 AWG
Wire   colors Black, brown, blue,   white, gray, pink
Material   conductor insulation TPE / PVC
Wire Length 500mm
Environmental   protection ROHS
Key Commercial Data
MOQ 100 PCS


Download: PDF
